Part Number	Manufacturer	Description	Package	Stock	Package	Series	Number of Channels	Voltage - Isolation	Current Transfer Ratio (Min)	Current Transfer Ratio (Max)	Turn On / Turn Off Time (Typ)	Rise / Fall Time (Typ)	Input Type	Output Type	Voltage - Output (Max)	Current - Output / Channel	Voltage - Forward (Vf) (Typ)	Current - DC Forward (If) (Max)	Vce Saturation (Max)	Operating Temperature	Mounting Type	Package / Case	Supplier Device Package
TCMT1600	Vishay Semiconductor Opto Division	OPTOISOLATOR 3.75KV TRANS 4-SOP	Package: 4-SOIC (0.173", 4.40mm)	Stock247,104	4-SOIC (0.173", 4.40mm)	-	1	3750Vrms	80% @ 5mA	300% @ 5mA	6µs, 5µs	3µs, 4.7µs	AC, DC	Transistor	70V	50mA	1.35V	60mA	300mV	-40°C ~ 100°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-SOP
ELD207(TA)-V	Everlight Electronics Co Ltd	OPTOISO 3.75KV 2CH TRANS 8-SOP	Package: 8-SOIC (0.154", 3.90mm Width)	Stock17,772	8-SOIC (0.154", 3.90mm Width)	-	2	3750Vrms	100% @ 10mA	200% @ 10mA	5µs, 4µs	1.6µs, 2.2µs	DC	Transistor	80V	-	1.2V	60mA	400mV	-55°C ~ 110°C	Surface Mount	8-SOIC (0.154", 3.90mm Width)	8-SOP
TCLT1003	Vishay Semiconductor Opto Division	OPTOISOLATR 5KV TRANSISTOR 4-SOP	Package: 4-SMD, Gull Wing	Stock348,732	4-SMD, Gull Wing	-	1	5000Vrms	100% @ 10mA	200% @ 10mA	6µs, 5µs	3µs, 4.7µs	DC	Transistor	70V	50mA	1.25V	60mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SOP (2.54mm)
TCLT1008	Vishay Semiconductor Opto Division	OPTOISOLATR 5KV TRANSISTOR 4-SOP	Package: 4-SMD, Gull Wing	Stock135,192	4-SMD, Gull Wing	-	1	5000Vrms	130% @ 5mA	260% @ 5mA	6µs, 5µs	3µs, 4.7µs	DC	Transistor	70V	50mA	1.25V	60mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SOP (2.54mm)
TCLT1007	Vishay Semiconductor Opto Division	OPTOISOLATR 5KV TRANSISTOR 4-SOP	Package: 4-SMD, Gull Wing	Stock65,412	4-SMD, Gull Wing	-	1	5000Vrms	80% @ 5mA	160% @ 5mA	6µs, 5µs	3µs, 4.7µs	DC	Transistor	70V	50mA	1.25V	60mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SOP (2.54mm)
HCPL-354-06AE	Broadcom Limited	OPTOISO 3.75KV TRANS 4MINIFLAT	Package: 4-SMD, Gull Wing	Stock9,276	4-SMD, Gull Wing	-	1	3750Vrms	50% @ 1mA	150% @ 1mA	-	4µs, 3µs	AC, DC	Transistor	35V	50mA	1.2V	50mA	200mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-Mini-Flat
PS2705A-1-F3-A	CEL	OPTOISOLATOR 3.75KV TRANS 4SMD	Package: 4-SMD, Gull Wing	Stock308,400	4-SMD, Gull Wing	NEPOC	1	3750Vrms	50% @ 5mA	300% @ 5mA	-	5µs, 7µs	AC, DC	Transistor	70V	30mA	1.2V	30mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SOP
HMHA2801AR2V	Fairchild/ON Semiconductor	OPTOISO 3.75KV TRANS 4-MINI-FLAT	Package: 4-SOIC (0.173", 4.40mm)	Stock72,000	4-SOIC (0.173", 4.40mm)	-	1	3750Vrms	80% @ 5mA	160% @ 5mA	-	3µs, 3µs	DC	Transistor	80V	50mA	1.3V (Max)	50mA	300mV	-55°C ~ 100°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-Mini-Flat
TCMT1100	Vishay Semiconductor Opto Division	OPTOISOLATOR 3.75KV TRANS 4-SOP	Package: 4-SOIC (0.173	Stock1,539,828	4-SOIC (0.173", 4.40mm)	-	1	3750Vrms	50% @ 5mA	600% @ 5mA	9.5µs, 8.5µs	5.5µs, 7µs	DC	Transistor	70V	50mA	1.35V	60mA	300mV	-40°C ~ 100°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-SOP
TCMT1107	Vishay Semiconductor Opto Division	OPTOISOLATOR 3.75KV TRANS 4-SOP	Package: 4-SOIC (0.173", 4.40mm)	Stock975,780	4-SOIC (0.173", 4.40mm)	-	1	3750Vrms	80% @ 5mA	160% @ 5mA	9.5µs, 8.5µs	5.5µs, 7µs	DC	Transistor	70V	50mA	1.35V	60mA	300mV	-40°C ~ 100°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-SOP
PS2561L-1-F3-A	CEL	OPTOISOLATOR 5KV TRANS 4SMD	Package: 4-SMD, Gull Wing	Stock21,600	4-SMD, Gull Wing	NEPOC	1	5000Vrms	80% @ 5mA	400% @ 5mA	-	3µs, 5µs	DC	Transistor	80V	50mA	1.17V	80mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SMD
ACPL-214-500E	Broadcom Limited	OPTOISOLATOR 3KV TRANS 4SOIC	Package: 4-SOIC (0.173", 4.40mm)	Stock198,000	4-SOIC (0.173", 4.40mm)	-	1	3000Vrms	20% @ 1mA	400% @ 1mA	3µs, 3µs	2µs, 3µs	AC, DC	Transistor	80V	50mA	1.2V	50mA	400mV	-55°C ~ 110°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-SO
PS2701-1-F3-L-A	CEL	OPTOISOLATOR 3.75KV TRANS 4SMD	Package: 4-SMD, Gull Wing	Stock274,344	4-SMD, Gull Wing	NEPOC	1	3750Vrms	100% @ 5mA	300% @ 5mA	-	3µs, 5µs	DC	Transistor	40V	80mA	1.1V	50mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SMD
PS2701-1-F3-A	CEL	OPTOISOLATOR 3.75KV TRANS 4SMD	Package: 4-SMD, Gull Wing	Stock3,728,928	4-SMD, Gull Wing	NEPOC	1	3750Vrms	50% @ 5mA	300% @ 5mA	-	3µs, 5µs	DC	Transistor	40V	80mA	1.1V	50mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SMD
FODM121R2	Fairchild/ON Semiconductor	OPTOISO 3.75KV TRANSISTOR 4SMD	Package: 4-SMD, Gull Wing	Stock142,032	4-SMD, Gull Wing	-	1	3750Vrms	50% @ 5mA	600% @ 5mA	-	3µs, 3µs	DC	Transistor	80V	80mA	1.3V (Max)	50mA	400mV	-40°C ~ 110°C	Surface Mount	4-SMD, Gull Wing	4-Mini-Flat
HMHA281R2	Fairchild/ON Semiconductor	OPTOISO 3.75KV TRANSISTOR 4SOIC	Package: 4-SOIC (0.173", 4.40mm)	Stock36,408	4-SOIC (0.173", 4.40mm)	-	1	3750Vrms	50% @ 5mA	600% @ 5mA	-	3µs, 3µs	DC	Transistor	80V	50mA	1.3V (Max)	50mA	400mV	-55°C ~ 100°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-Mini-Flat
HMHA2801R2	Fairchild/ON Semiconductor	OPTOISO 3.75KV TRANSISTOR 4SMD	Package: 4-SOIC (0.173", 4.40mm)	Stock124,368	4-SOIC (0.173", 4.40mm)	-	1	3750Vrms	80% @ 5mA	600% @ 5mA	-	3µs, 3µs	DC	Transistor	80V	50mA	1.3V (Max)	50mA	300mV	-55°C ~ 100°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-Mini-Flat
ACPL-217-56BE	Broadcom Limited	OPTOISOLATOR 3KV TRANSISTOR 4-SO	Package: 4-SOIC (0.173", 4.40mm)	Stock9,540	4-SOIC (0.173", 4.40mm)	-	1	3000Vrms	130% @ 5mA	260% @ 5mA	3µs, 3µs	2µs, 3µs	DC	Transistor	80V	50mA	1.2V	50mA	400mV	-55°C ~ 110°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-SO
VOL617A-3T	Vishay Semiconductor Opto Division	OPTOISOLATOR 5KV TRANS 4-LSOP	Package: 4-SMD, Gull Wing	Stock6,636	4-SMD, Gull Wing	-	1	5000Vrms	100% @ 5mA	200% @ 5mA	6µs, 5.5µs	3.5µs, 5µs	DC	Transistor	80V	50mA	1.16V	60mA	400mV	-55°C ~ 110°C	Surface Mount	4-SMD, Gull Wing	4-LSOP (2.54mm)
PS2501L-1-F3-L-A	CEL	OPTOISOLATOR 5KV TRANS 4SMD	Package: 4-SMD, Gull Wing	Stock385,296	4-SMD, Gull Wing	NEPOC	1	5000Vrms	200% @ 5mA	400% @ 5mA	-	3µs, 5µs	DC	Transistor	80V	50mA	1.17V	80mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SMD
PS2501L-1-F3-A	CEL	OPTOISOLATOR 5KV TRANS 4SMD	Package: 4-SMD, Gull Wing	Stock183,420	4-SMD, Gull Wing	NEPOC	1	5000Vrms	80% @ 5mA	600% @ 5mA	-	3µs, 5µs	DC	Transistor	80V	50mA	1.17V	80mA	300mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SMD
FOD814ASD	Fairchild/ON Semiconductor	OPTOISOLATOR 5KV TRANSISTOR 4SMD	Package: 4-SMD, Gull Wing	Stock14,208	4-SMD, Gull Wing	-	1	5000Vrms	50% @ 1mA	150% @ 1mA	-	4µs, 3µs	AC, DC	Transistor	70V	50mA	1.2V	50mA	200mV	-55°C ~ 105°C	Surface Mount	4-SMD, Gull Wing	4-SMD
FODM121AR2	Fairchild/ON Semiconductor	OPTOISO 3.75KV TRANSISTOR 4SMD	Package: 4-SMD, Gull Wing	Stock382,812	4-SMD, Gull Wing	-	1	3750Vrms	100% @ 5mA	300% @ 5mA	-	3µs, 3µs	DC	Transistor	80V	80mA	1.3V (Max)	50mA	400mV	-40°C ~ 110°C	Surface Mount	4-SMD, Gull Wing	4-Mini-Flat
ACPL-217-500E	Broadcom Limited	OPTOISOLATOR 3KV TRANS 4SOIC	Package: 4-SOIC (0.173", 4.40mm)	Stock589,104	4-SOIC (0.173", 4.40mm)	-	1	3000Vrms	50% @ 5mA	600% @ 5mA	3µs, 3µs	2µs, 3µs	DC	Transistor	80V	50mA	1.2V	50mA	400mV	-55°C ~ 110°C	Surface Mount	4-SOIC (0.173", 4.40mm)	4-SO
LTV-814S-TA1	Lite-On Inc.	OPTOISOLATR 5KV TRANSISTOR 4-SMD	Package: 4-SMD, Gull Wing	Stock390,276	4-SMD, Gull Wing	-	1	5000Vrms	20% @ 1mA	300% @ 1mA	-	4µs, 3µs	AC, DC	Transistor	35V	50mA	1.2V	50mA	200mV	-30°C ~ 110°C	Surface Mount	4-SMD, Gull Wing	4-SMD
HCPL-181-00BE	Broadcom Limited	OPTOISO 3.75KV TRANS 4MINIFLAT	Package: 4-SMD, Gull Wing	Stock713,940	4-SMD, Gull Wing	-	1	3750Vrms	130% @ 5mA	260% @ 5mA	-	4µs, 3µs	DC	Transistor	80V	50mA	1.2V	50mA	200mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-Mini-Flat
HCPL-817-56CE	Broadcom Limited	OPTOISOLATOR 5KV TRANSISTOR 4SMD	Package: 4-SMD, Gull Wing	Stock520,578	4-SMD, Gull Wing	-	1	5000Vrms	200% @ 5mA	400% @ 5mA	-	4µs, 3µs	DC	Transistor	70V	50mA	1.2V	50mA	200mV	-30°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-SMD
HCPL-181-00CE	Broadcom Limited	OPTOISO 3.75KV TRANS 4MINIFLAT	Package: 4-SMD, Gull Wing	Stock863,244	4-SMD, Gull Wing	-	1	3750Vrms	200% @ 5mA	400% @ 5mA	-	4µs, 3µs	DC	Transistor	80V	50mA	1.2V	50mA	200mV	-55°C ~ 100°C	Surface Mount	4-SMD, Gull Wing	4-Mini-Flat
HCPL-181-000E	Broadcom Limited	OPTOISO 3.75KV TRANSISTOR 4SOIC	Package: 4-SOIC (0.209", 5.30mm Width)	Stock469,308	4-SOIC (0.209", 5.30mm Width)	-	1	3750Vrms	50% @ 5mA	600% @ 5mA	-	4µs, 3µs	DC	Transistor	80V	50mA	1.2V	50mA	200mV	-55°C ~ 100°C	Surface Mount	4-SOIC (0.209", 5.30mm Width)	4-SO
LTV-355T	Lite-On Inc.	OPTOISO 3.75KV DARLINGTON 4SOP	Package: 4-SMD, Gull Wing	Stock2,000	4-SMD, Gull Wing	-	1	3750Vrms	600% @ 1mA	7500% @ 1mA	-	60µs, 53µs	DC	Darlington	35V	80mA	1.2V	50mA	1V	-55°C ~ 110°C	Surface Mount	4-SMD, Gull Wing	4-SOP (2.54mm)

Optoisolators - Transistor, Photovoltaic Output
